详解JAVA线程问题诊断工具Thread Dump

synchronized(obj) {
   .........
   obj.wait();
   .........
}

public enum State
{
       /**
        * Thread state for a thread which has not yet started.
        */
       NEW,
       /**
        * Thread state for a runnable thread.  A thread in the runnable
        * state is executing in the Java virtual machine but it may
        * be waiting for other resources from the operating system
        * such as processor.
        */
       RUNNABLE,
       /**
        * Thread state for a thread blocked waiting for a monitor lock.
        * A thread in the blocked state is waiting for a monitor lock
        * to enter a synchronized block/method or
        * reenter a synchronized block/method after calling
        * {@link Object#wait() Object.wait}.
        */
       BLOCKED,
       /**
        * Thread state for a waiting thread.
        * A thread is in the waiting state due to calling one of the
        * following methods:
        * <ul>
        *   <li>{@link Object#wait() Object.wait} with no timeout</li>
        *   <li>{@link #join() Thread.join} with no timeout</li>
        *   <li>{@link LockSupport#park() LockSupport.park}</li>
        * </ul>
        *
        * <p>A thread in the waiting state is waiting for another thread to
        * perform a particular action.
        *
        * For example, a thread that has called <tt>Object.wait()</tt>
        * on an object is waiting for another thread to call
        * <tt>Object.notify()</tt> or <tt>Object.notifyAll()</tt> on
        * that object. A thread that has called <tt>Thread.join()</tt>
        * is waiting for a specified thread to terminate.
        */
       WAITING,
       /**
        * Thread state for a waiting thread with a specified waiting time.
        * A thread is in the timed waiting state due to calling one of
        * the following methods with a specified positive waiting time:
        * <ul>
        *   <li>{@link #sleep Thread.sleep}</li>
        *   <li>{@link Object#wait(long) Object.wait} with timeout</li>
        *   <li>{@link #join(long) Thread.join} with timeout</li>
        *   <li>{@link LockSupport#parkNanos LockSupport.parkNanos}</li>
        *   <li>{@link LockSupport#parkUntil LockSupport.parkUntil}</li>
        * </ul>
        */
       TIMED_WAITING,
       /**
        * Thread state for a terminated thread.
        * The thread has completed execution.
        */
       TERMINATED;
}

synchronized(obj) {
   .........
}

package jstack;
public class BlockedState
{
    private static Object object = new Object();
    public static void main(String[] args)
    {
        Runnable task = new Runnable() {
            @Override
            public void run()
            {
                synchronized (object)
                {
                    long begin = System.currentTimeMillis();
                    long end = System.currentTimeMillis();
                    // 让线程运行5分钟,会一直持有object的监视器
                    while ((end - begin) <= 5 * 60 * 1000)
                    {
                    }
                }
            }
        };
        new Thread(task, "t1").start();
        new Thread(task, "t2").start();
    }
}

Full thread dump Java HotSpot(TM) Server VM (20.12-b01 mixed mode):
"DestroyJavaVM" prio=6 tid=0x00856c00 nid=0x1314 waiting on condition [0x00000000]
java.lang.Thread.State: RUNNABLE
"t2" prio=6 tid=0x27d7a800 nid=0x1350 waiting for monitor entry [0x2833f000]
java.lang.Thread.State: BLOCKED (on object monitor)
     at jstack.BlockedState$1.run(BlockedState.java:17)
     - waiting to lock <0x1cfcdc00> (a java.lang.Object)
     at java.lang.Thread.run(Thread.java:662)
"t1" prio=6 tid=0x27d79400 nid=0x1338 runnable [0x282ef000]
 java.lang.Thread.State: RUNNABLE
     at jstack.BlockedState$1.run(BlockedState.java:22)
     - locked <0x1cfcdc00> (a java.lang.Object)
     at java.lang.Thread.run(Thread.java:662)

package jstack;
public class WaitingState
{
    private static Object object = new Object();
    public static void main(String[] args)
    {
        Runnable task = new Runnable() {
            @Override
            public void run()
            {
                synchronized (object)
                {
                    long begin = System.currentTimeMillis();
                    long end = System.currentTimeMillis();
                    // 让线程运行5分钟,会一直持有object的监视器
                    while ((end - begin) <= 5 * 60 * 1000)
                    {
                        try
                        {
                            // 进入等待的同时,会进入释放监视器
                            object.wait();
                        } catch (InterruptedException e)
                        {
                            e.printStackTrace();
                        }
                    }
                }
            }
        };
        new Thread(task, "t1").start();
        new Thread(task, "t2").start();
    }
}
Full thread dump Java HotSpot(TM) Server VM (20.12-b01 mixed mode):
"DestroyJavaVM" prio=6 tid=0x00856c00 nid=0x1734 waiting on condition [0x00000000]
java.lang.Thread.State: RUNNABLE
"t2" prio=6 tid=0x27d7e000 nid=0x17f4 in Object.wait() [0x2833f000]
java.lang.Thread.State: WAITING (on object monitor)
     at java.lang.Object.wait(Native Method)
     - waiting on <0x1cfcdc00> (a java.lang.Object)
     at java.lang.Object.wait(Object.java:485)
     at jstack.WaitingState$1.run(WaitingState.java:26)
     - locked <0x1cfcdc00> (a java.lang.Object)
     at java.lang.Thread.run(Thread.java:662)
"t1" prio=6 tid=0x27d7d400 nid=0x17f0 in Object.wait() [0x282ef000]
java.lang.Thread.State: WAITING (on object monitor)
     at java.lang.Object.wait(Native Method)
     - waiting on <0x1cfcdc00> (a java.lang.Object)
     at java.lang.Object.wait(Object.java:485)
     at jstack.WaitingState$1.run(WaitingState.java:26)
     - locked <0x1cfcdc00> (a java.lang.Object)
     at java.lang.Thread.run(Thread.java:662)

package jstack;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.locks.Condition;
import java.util.concurrent.locks.Lock;
import java.util.concurrent.locks.ReentrantLock;
public class TimedWaitingState
{
    // java的显示锁,类似java对象内置的监视器
    private static Lock lock = new ReentrantLock();
    // 锁关联的条件队列(类似于object.wait)
    private static Condition condition = lock.newCondition();
    public static void main(String[] args)
    {
        Runnable task = new Runnable() {
            @Override
            public void run()
            {
                // 加锁,进入临界区
                lock.lock();
                try
                {
                    condition.await(5, TimeUnit.MINUTES);
                } catch (InterruptedException e)
                {
                    e.printStackTrace();
                }
                // 解锁,退出临界区
                lock.unlock();
            }
        };
        new Thread(task, "t1").start();
        new Thread(task, "t2").start();
    }
}
Full thread dump Java HotSpot(TM) Server VM (20.12-b01 mixed mode):
"DestroyJavaVM" prio=6 tid=0x00856c00 nid=0x169c waiting on condition [0x00000000]
java.lang.Thread.State: RUNNABLE
"t2" prio=6 tid=0x27d7d800 nid=0xc30 waiting on condition [0x2833f000]
java.lang.Thread.State: TIMED_WAITING (parking)
     at sun.misc.Unsafe.park(Native Method)
     - parking to wait for  <0x1cfce5b8> (a java.util.concurrent.locks.AbstractQueuedSynchronizer$ConditionObject)
     at java.util.concurrent.locks.LockSupport.parkNanos(LockSupport.java:196)
     at java.util.concurrent.locks.AbstractQueuedSynchronizer$ConditionObject.await(AbstractQueuedSynchronizer.java:2116)
     at jstack.TimedWaitingState$1.run(TimedWaitingState.java:28)
     at java.lang.Thread.run(Thread.java:662)
"t1" prio=6 tid=0x280d0c00 nid=0x16e0 waiting on condition [0x282ef000]
java.lang.Thread.State: TIMED_WAITING (parking)
     at sun.misc.Unsafe.park(Native Method)
     - parking to wait for  <0x1cfce5b8> (a java.util.concurrent.locks.AbstractQueuedSynchronizer$ConditionObject)
     at java.util.concurrent.locks.LockSupport.parkNanos(LockSupport.java:196)
     at java.util.concurrent.locks.AbstractQueuedSynchronizer$ConditionObject.await(AbstractQueuedSynchronizer.java:2116)
     at jstack.TimedWaitingState$1.run(TimedWaitingState.java:28)
     at java.lang.Thread.run(Thread.java:662)

"Thread-1" prio=5 tid=0x00acc490 nid=0xe50 waiting for monitor entry [0x02d3f000
..0x02d3fd68]
at deadlockthreads.TestThread.run(TestThread.java:31)
- waiting to lock <0x22c19f18> (a java.lang.Object)
- locked <0x22c19f20> (a java.lang.Object)
"Thread-0" prio=5 tid=0x00accdb0 nid=0xdec waiting for monitor entry [0x02cff000
..0x02cff9e8]
at deadlockthreads.TestThread.run(TestThread.java:31)
- waiting to lock <0x22c19f20> (a java.lang.Object)
- locked <0x22c19f18> (a java.lang.Object)

Found one Java-level deadlock:
=============================
"Thread-1":
waiting to lock monitor 0x0003f334 (object 0x22c19f18, a java.lang.Object),
which is held by "Thread-0"
"Thread-0":
waiting to lock monitor 0x0003f314 (object 0x22c19f20, a java.lang.Object),
which is held by "Thread-1"
